Air Conditioner Keeps Blowing Fuse in Circuit Board

Air Conditioner Keeps Blowing Fuse in Circuit Board

Having a functional air conditioner is essential for maintaining a comfortable indoor environment, especially during hot summer months. However, encountering issues with your AC unit can be frustrating, and one common problem is when the air conditioner keeps blowing the fuse in the circuit board.

We will explore the possible causes behind this issue and provide troubleshooting tips to help you resolve it. Remember, if you’re unsure or uncomfortable handling electrical components, it’s always best to consult a professional technician.


Understanding the Circuit Board and Fuses

The circuit board, also known as the control board or PCB (Printed Circuit Board), is a crucial component in your air conditioning system. It acts as the “brain” of the unit, controlling various functions such as temperature regulation, fan speed, and compressor operation. Fuses are safety devices designed to protect electrical circuits from overloads or short circuits by breaking the electrical connection when an abnormal current flows through them.


Possible Causes for Blown Fuses

1. Electrical Overload: An electrical overload occurs when the air conditioner draws more current than the circuit can handle. This can happen due to several reasons, such as a malfunctioning compressor, a faulty motor, or a damaged electrical component within the AC unit. The increased electrical load exceeds the fuse’s rated capacity, causing it to blow.


2. Short Circuits: Short circuits happen when a hot wire comes into contact with a neutral or ground wire, resulting in an abnormal flow of current. This can be caused by exposed wires, damaged insulation, or faulty connections within the air conditioner. A short circuit creates a sudden surge of current, causing the fuse to blow as a safety measure.


3. Improper Wiring: In some cases, the issue may stem from incorrect or inadequate wiring. If the electrical connections within the air conditioning system are not properly installed or are loose, it can lead to fluctuating currents and cause fuses to blow repeatedly.


Troubleshooting Steps

1. Check for Overheating Components: Inspect the air conditioner’s outdoor unit for overheating components. A malfunctioning compressor or condenser fan motor can cause excessive heat build-up. If you notice any signs of overheating, such as burning smells, hot surfaces, or unusual noises, it’s crucial to contact a professional technician to address the issue promptly.


2. Inspect for Short Circuits: Examine the wiring and electrical connections within the air conditioner. Look for any exposed wires, frayed insulation, or loose connections. If you find any signs of damage or suspect a short circuit, it’s best to have a qualified technician repair or replace the faulty wiring to prevent further issues.


3. Evaluate Electrical Load: Determine if the electrical load in your air conditioner is within the circuit’s capacity. Check the unit’s specifications and compare them to the rating of the fuse in the circuit board. If the air conditioner’s electrical requirements exceed the fuse’s capacity, it may be necessary to install a fuse with a higher rating. However, this should only be done by a licensed electrician to ensure safety and compliance with electrical codes.


4. Seek Professional Assistance: If you have gone through the troubleshooting steps mentioned above and the issue persists, it’s advisable to contact a professional electrician or HVAC technician. They have the expertise and tools to diagnose the problem accurately and perform the necessary repairs or replacements.



Dealing with a blown fuse in your air conditioner’s circuit board can be inconvenient and frustrating. By understanding the possible causes and following the troubleshooting steps mentioned above, you can identify and address the issue effectively. However, if you’re uncertain about handling electrical components or unable to resolve the problem on your own, it’s always best to seek professional assistance from a qualified HVAC technician.
